Apraksts
Synchronization at a height difference of 30 mm.
Each column has a control panel.
Available configurations include 4, 6, or 8 columns.
Features a mechanical locking system.
Wireless 2.4 GHz communication ensures seamless operation between columns.
Automatic gear selection with screen indication for precise control.
All columns are identical for easy setup and use. Electrohydraulic, wireless, battery powered.
Technical Specifications:
Lifting capacity: 7500 kg per column; total 30000 kg
Motor power: 3 kW
Column weight: 650 kg
Lifting time: 90 s
Lowering time: 45 s
Maximum tire diameter: 1200 mm
Minimum tire diameter: 500 mm
Minimum rim diameter: 580 mm
Operating Modes:
ALL – All columns operate simultaneously.
GROUP – Selected pairs of columns operate together.
SINGLE – Individual column operation.
