Apraksts
Bandwidth: 100 MHz;
Channel: 4;
Rise Time: ≤3.5 ns;
Real-time Sampling Rate: 1G Sa/s;
Trigger Mode: Edge, Pulse
Trigger Method: Automatic, Normal, Single;
Memory Depth: 50 Mpts;
Auto Measurement: Period, Frequency, Rise Time, Fall Time, Delay, Positive Duty, Cycle, Negative Duty Cycle, Positive Pulse Width, Negative Pulse Width, Burst Width, Positive Overshoot, Negative Overshoot, Phase, Peak-to-Peak, Amplitude, High, Low, Maximum, Minimum, RMS, Cycle RMS, Mean, Cycle Mean;
Input Impedance: 1MQ±1%//14pF;
Interface: USB Type-C, DC Power;
Support Test: Charging/Start Circuits, Sensors, Actuators, Ignition, Networks (CAN L/H, CAN FD, LIN, Flexray, K line), Combination Tests;
Battery: 7.4V, 7500m Ah, Li-Ion battery;
DC Gain Accuracy: ≤ 2%;
Size	: 140x215x52 mm;
Net Weight: 640g;
