Description
Capacity: 10 T;
Stroke: 175 mm;
Dimensions: 680x450x1070 mm;
Net weight: 45.2 kg;
Large diameter hydraulic steel cylinder unit results in lower oil pressure needed to raise the load, helping to reduce wear;
Piston-ram is treated and polished to resist skiving;
Piston-ram utilizes a Y-Style polyurethane sealing ring with backup ring, preventing load from falling slowly.
