⬡ Multi-stage hydraulic cylinder ram 30 t (54 mm) (TRB3030, TONGRUN)
Capacity 30/15/5 t
Lifting height per stage 12/22/20 mm
Min height 64 mm
Max height 118 mm
Total lifting height 54 mm
Cylinder diameter 75/50/30 mm
Connection 3/8"
Weight 4.4 kg
Suitable pump:
Oil capacity 900 ml
Working pressure (low/high) 20/700 bar
Oil volume/each pump (low/high pressure) 13/2.3 ml
