Description
Technical specifications:
Lifting Capacity per Column: 8500 kg (6x8500 kg)
Maximum Wheel Diameter: 1200 mm
Minimum Wheel Diameter: 900 mm
Motor Power: 3.7 kW
Lifting Height: 1760 mm
Column Height: 2725 mm
Cable communication system
Designed for indoor use
Electronic column synchronization
Electromechanical control system
Each column is portable and equipped with wheels
Total lifting capacity: 51,000 kg (6x8500 kg)
Required power supply: 400V – 50 Hz
