Description
Technical specification:
Lifting capacity per column: 2500 kg (4 x 2500 kg)
Maximum wheel diameter: 780 mm
Minimum wheel diameter: 550 mm
Lifting time: 60 s
Motor power: 3.0 kW
Lifting height: 1800 mm
Column height: 2730 mm
Suitable for indoor use
Electronic column synchronization
Electromechanical control
Each column is transportable – equipped with wheels
Total lifting capacity: 10,000 kg (4 x 2500 kg)
Required power supply: 400V – 50 Hz
Motor power: 3.0 kW
