Code PDB2-50.19-K35
Floor-level anchored 2-ram lift 3.5 t, K 35 swing-arm support, 1,900 mm stroke (PDB2-50.19-K35, PITLIFT)
Description
PDB2 series floor-level (recessed) anchored 2-ram lift (with CE-Stop) with swing-arm support (RAL7016), galvanized lifting arms and standard support plates (75), hydraulic power unit, control box and covers; supplied without hydraulic oil, anchors not included.
- Capacity: 3.5 t
- Stroke: 1,900 mm
- Arm extension length: 560–1,140 mm
- Ram diameter: 2x125 mm
- Ram spacing: 1,350 mm
- Covers for clear opening: 1,800 x 410 x 25 mm
- Hydraulic oil volume: 100 l (oil not supplied)
- Anchors not included
