Description
Activation: Special card
LCD screen: YES 4.3"
OCPP (Open Charge Point Protocol) TYPE2: NO
DLB (Dynamic load balance): YES
APP: YES (WeGoodCharger)
Wifi/Bluetooth: YES
Cable length: 5 m
Cable size: 5*6mm² + 0.75mm² (Required circuit breaker C63 4P)
Charging power: 22 kW (Power output ranges: from 3.5 - 22kw) (standby mode 3W)
Switch type: IEC 62196-2
Voltage range: 380 V
Nominal current: 32 A (Adjustable range: 8 - 32 A)
Equipped with comprehensive protection functions: overvoltage and undervoltage protection, overcurrent protection for AC input and output, output current limiting, overcurrent protection
Operating temperature: -30℃ to 50℃
IP protection lever: IP65
Installation: Wall-mounted
Dimensions: 410 x 410 x 120 mm
Packing box: 485 x 290 x 215 mm
Weight: 5 kg
Warranty: 12 months
