Description
- Carrying capacity, T 4.5
- Lifting height, mm 109-1979
- Lifting speed, s 30
- Distance between columns, mm 2916
- Passage width mm 2602
- Internal height of the lift, mm 4675
- Lift external height 4780
- Length of short lifting supports, mm 700-1500 (three positions)
- Length of long supports, mm 700-1500 (three positions)
- Power supply, 400 V, 50 Hz
- Engine 4.0 Kw
- Made in Germany
- Warranty 12 months
Control of the lift on the piled columns
With electromagnetic shutters
Powder coated RAL7040/7012
