Description
Features:
Foot brake - The built-in foot brake makes it quick and easy to clean the surface and attach new weights.
Versatility - Selectable steering programs: Static, Alu1, Alu2, Alu3, etc.
Reliability - 40mm balance shaft with rust resistant aluminum alloy belt pulley ensures machine reliability.
Accurate Measurement - Aluminum alloy distance meter with weight holder ensures more accurate measurement.
Wheel lifter - An air-operated wheel lifter will make heavy wheel installation jobs easier.
Technical characteristics
Rim diameter: 7" - 39"
Axle diameter: 40mm
Max. Tire diameter: 1200mm
Tire width: 1.1"- 35"
Max. Tire weight: 150 kg
Rotation speed: 200rpm
Balance accuracy: ± 5g
Motor: 0.55 kW
Power supply: 380 V | 50 - 60 Hz
Weight: 225 kg
Standard equipment:
Centering cones - 5 pcs
Quick release handle - 1
Pliers for weights - 1
Ruler for measuring rim width - 1
Calibration weight - 1
Powder coated RAL7016
